SUZUKI Oil Seal

A Suzuki oil seal is a mechanical seal used to seal the gaps between the rotating shaft and the stationary housing in a device such as an engine or gearbox. The seal is typically made of rubber or rubber-like material, and it is designed to prevent oil leaks by creating a barrier between the internal moving parts of the device and the outside environment.

Product Description

A Suzuki oil seal is a mechanical seal used to seal the gaps between the rotating shaft and the stationary housing in a device such as an engine or gearbox. The seal is typically made of rubber or rubber-like material, and it is designed to prevent oil leaks by creating a barrier between the internal moving parts of the device and the outside environment. Suzuki oil seals are commonly used in a wide range of vehicles and machinery and are known for their durability and reliability. They are an essential component in maintaining the proper functioning of a vehicle or machine by keeping lubricants in and contaminants out.

Advantages of KDIK Quality SUZUKI OIL SEALS



♦ The primary function of these seals is to prevent oil leaks, ensuring your engine remains clean and efficient.

♦ A well-sealed engine operates at peak performance, improving fuel efficiency and power output.

♦ Quality seals extend the lifespan of your engine components, saving you money on repairs.

♦ With fewer oil leaks, you'll spend less time and money on maintenance.



Types of SUZUKI OIL SEALS



♦ Crankshaft Seals: These seals are installed at the front and rear of the crankshaft, preventing oil from escaping the engine's crankcase.

♦ Camshaft Seals: Found in the cylinder head, camshaft seals ensure that oil does not leak into the combustion chamber.

♦ Valve Stem Seals: These seals are located in the cylinder head and keep oil from entering the combustion chamber via the valve guides.

♦ Axle Seals: Installed in the vehicle's axles, they keep oil from escaping and contaminants from entering.

♦ Transmission Seals: These seals maintain the integrity of your transmission system by preventing leaks.



Check out the catalog below or ask us for one!



SUZUKI OIL SEALS
Transaxle (ATM) Sub Model / Engine OEM Payen No. Size
Differential Side (Front) (LH) RB21S 27431-60G10 NA5414 35x54x9.5x13.5
Differential Side (Front) (RH) RB21S 27441-60G10 NA5416 34x58x9.5x13
Rear (Inner & Outer) RA21S,RB21S,RC51S,RD51S:4WD 43431-60B20 NJ199 49x62x8x11
Camshaft F5A 3 CYL (OHC) 543 cc 09283-32002 NJ336 32x47x8
Camshaft F5A 3 CYL (OHC) 543 cc 09283-32022 NJ336 32x47x8
Camshaft F5A 3 CYL (OHC) 543 cc 09283-32016 NJ336 32x47x8
Camshaft F5A 3 CYL (OHC) 543 cc 09283-32003 NJ336 32x47x8
Camshaft F5A,B:CA#,CC#,CL#,CN#,CM#,CP# 09283-32038 NJ377 32x47x6
Camshaft F8A 4 CYL (OHC) 797 cc 09283-32025 NJ336 32x47x8
Camshaft F8A 4 CYL (OHC) 797 cc 96051420 NJ336 32x47x8
Crankshaft (Rear) F5A 3 CYL (OHC) 543 cc 09283-60005 NJ337 60x80x8
Crankshaft (Rear) F5A 3 CYL (OHC) 543 cc 09283-60003 NJ337 60x80x8
Differential Side (Front) (LH & RH) CM#,CP#,CS# (4WD) 27431-73B20 NA5415 35x52x8
Differential Side (Front) (LH & RH) CA71V,72V 27431-50A30 NJ850 30x54x9
Differential Side (Front) (LH & RH) SS30V 09283-35036 NJ851 35x72x7.5x9.5
Differential Side (Front) (LH) CL#,CN#,CR#...TURBO 09283-35037 NJ761 35x62x9.5
Input Shaft CC#,CL#,CM#,CN#,CP#,CR#,CS# 24151-73B01 NJ758 20x35x5.5
Front SS30V,40V 09283-44009 NJ854 44x62x8x14
Rear CC71V,72V (4WD) 09283-42008 NJ052 42x55x7
Clutch Side CL11V,21V,CN11S,21S...TURBO 09283-35025 NJ761 35x62x9.5
Clutch Side CL11V,21V,CN11S,21S...TURBO 96061932 NJ761 35x62x9.5
Clutch Side CL11V,21V,CN11S,21S...TURBO 09283-35024 NJ761 35x62x9.5
In CL11V...TURBO 09283-20040 NJ758 20x35x5.5
In CL21V,CM21V,CN21S,CP21S... DOHC,TURBO 96051419 NJ758 20x35x5.5
In CL21V,CM21V,CN21S,CP21S... DOHC,TURBO 24151-73B00 NJ758 20x35x5.5
Clutch Side SS30V 09283-35031 NJ851 35x72x7.5x9.5
Clutch Side SS30V 09283-35022 NJ851 35x72x7.5x9.5
Clutch Side SS30V 09283-35013 NJ851 35x72x7.5x9.5
Clutch Side SS40V 09283-30055 NJ850 30x54x9
Clutch Side SS40V 09283-30038 NJ850 30x54x9
Front SS30V,40V 09283-44007 NJ854 44x62x8x14
Front SS30V,40V 09283-44006 NJ854 44x62x8x14
Pinion (Front) DA,DB 09283-28010 NJ759 28x47x10
Pinion (Front) DA,DB:(MT.TURBO) 09283-35008 NJ740 35x62x10x16.5
Extension Housing DA,DC (2WD) 24780-79001 NJ855 28x38x10x15
Input Shaft DA#,DB# 09283-20028 NJ757 20x47x8.5
Front ST31 (4WD) 09283-40012 NJ853 40x72x9x15
Rear DA52V,W,DB52V 09283-48007 NJ562 48x62x9
Differential Side (Front) (LH) CH72V 0923-35037 NJ761 35x62x9.5
Crankshaft (Front) J18A:GC41 09283-45011 NA5413 45x63x7.5
Crankshaft (Rear) G10 4 CYL (OHC) 993 cc 09283-68002 NJ378 68x86x8
Crankshaft (Rear) G10 4 CYL (OHC) 993 cc 09283-68001 NJ378 68x86x8
Crankshaft (Rear) G13A 4 CYL (OHC) 1324 cc 96065634 NJ378 68x86x8
Crankshaft (Rear) G13A 4 CYL (OHC) 1324 cc 96051424 NJ378 68x86x8
Crankshaft (Rear) J18A:GC41 09283-98001 NA5143 98x116x10
Timing Cover G10 3 CYL (OHC) 993 cc 09283-32036 NJ377 32x47x6
Timing Cover G10 3 CYL (OHC) 993 cc 09283-32026 NJ377 32x47x6
Timing Cover G13A 4 CYL (OHC) 1324 cc 96051421 NJ377 32x47x6
Front (Inner) AA34,44,AB34,44,AF34 43430-60810 NK176 49x62x7x11
Front (Inner) GA11,21,GB21,31,GC21,41,GD21,31 43431-60G00 NA5417 49x65x7.5x36.5
Front (Outer) AA33,53,AB33,51,55 09283-53001 NJ912 53x68.2x7
Front (Outer) AA34,AF34:TWIN CAM 09283-56002 NK196 56x72x8
Transmission (Side) AA34,44,AB34,44 27432-60B01 NK110 35x52x9.5
Front (Inner) AK34,AH14,64,AJ14,64 30006767 NJ199 49x62x8x11
Front (Inner) AK34,AH14,64,AJ14,64 96059934 NJ199 49x62x8x11
Front (Inner) AK34,AH14,64,AJ14,64 09283-49002 NJ199 49x62x8x11
Front (Outer) AA34,44,AB34,44 96055290 NJ912 53x68.2x7
Pinion (Front) ALL 09283-40027 NK265 40x72x11x18.5
Camshaft RF:TA31W,TD31W,32W BP01 10 602A NJ448 30x44x7
Crankshaft (Rear) H20A,H25A,H27A:TA11W,11W,61W, 62W,TX92W 09283-98002 NA5143 98x116x10
Crankshaft (Rear) RF:TA31W,TD31W,32W F801 11 399 NJ325 90x110x9
Front (Inner)(No.2) TA01#,11W,31W,51W 09286-64001 NK266 64x72x82x7x10
Front (Outer)(No.1) TA01#,11W,31W,51W 09283-54001 NJ992 54x69x7.5
Front (Outer)(No.2) TA01#,11W,31W,51W 09286-75001 NJ198 26x45x9
Rear (Inner) TA01#,11W,31W,51W 09282-48003 NJ991 48x62x9
Rear (Inner) TA02W,52W,TD02W,32W,52W,62W, TL52W 43592-65D00 NA5418 51x71x9
Rear (Outer) TA01#,11W,31W,51W 09284-45001 NK012 45x59x8
Drive Shaft (Front) JA11,12,22,51,71 09283-26016 NJ849 26x38x8
Front (Inner) JA11,51,71 09283-50002 NJ701 50x68x7x10
Front (Outer) TA01 96057747 NJ198 26x45x9
Rear (Outer) TA01 96057745 NK012 45x59x8
Differential Side (Front) (LH & RH) CT21S,51S:3AT:TURBO 27611-82300 NJ092 35x55x8
Rear JA51 24780-83000 NJ962 32x42x10x15
Front JA11,51,71 09283-50001 NJ701 50x68x7x10
Front (Shaft) JA11,51,71 09283-26010 NJ849 26x38x8



SUZUKI Oil Seal



How to Maintain SUZUKI OIL SEALS



♦ Regular Inspections: Periodically check for oil leaks and have worn seals replaced promptly.

♦ Change Oil Regularly: Timely oil changes can prevent sludge buildup, which can damage your seals.

♦ Use Quality Oil: High-quality oil can extend the life of your seals.

♦ Avoid Overfilling: Overfilling your engine with oil can put extra pressure on the seals.



SUZUKI Oil Seals supply in China - Buy the same quality SUZUKI Oil Seals at a low price



KDIK offers 100% SUZUKI Oil Seals using application-specific materials to provide you with the best sealing solution.We carry out various quality checks on our entire range at every stage of oil seal development. We ensure that the entire product range is flawless before delivering the entire container of oil seals to the customer. Our goal is to provide the best and highest quality products to meet the needs of our customers, whether they are large industries, spare parts distributors or repair stores around the world.Choose KDIK for your SUZUKI Oil Seals so you can replace your expensive brand name oil seal supplier! Contact us today to order.



FAQs about SUZUKI OIL SEAL



What are SUZUKI OIL SEALS made of?

SUZUKI OIL SEALS are typically made from synthetic rubber or silicone, chosen for their durability and resistance to oil.



How often should I replace SUZUKI OIL SEALS?

The frequency of replacement depends on various factors, but a good rule of thumb is every 60,000 to 100,000 miles.



Can I replace SUZUKI OIL SEALS myself?

While it's possible, it's best to leave this job to a professional mechanic, as improper installation can lead to leaks.



What are the signs of a failing SUZUKI OIL SEAL?

Common signs include oil leaks, reduced engine performance, and a burning oil smell.
