Custom-designed Skiving Roller Burnishing Machine
EOOE specialises in the development and manufacture of CNC skiving roller burnishing machine and strives to solve various processing problems for our customers. The key equipment configuration is in imported original packaging.
Product Description
Skiving and Roller Burnishing is a single process in two parts, where the blank is first removed with a turning tool and then the metal surface is cold finished with a tumbler to achieve the highest surface finish tolerances. This process is commonly used to finish hydraulic and pneumatic cylinders.
I、Main Parameters
|
Type |
SRB2500/250NC2W |
|
Maximum ID |
φ250mm |
|
Length |
2500mm |
|
Machining Method |
Workpiece Fixation, Tool Rotation |
|
Type |
SRB3000/300NC1W |
|
Maximum ID |
300mm |
|
Length |
3000mm |
|
Machining Method |
Workpiece Fixation, Tool Rotation |
|
Type |
SRB3000/420NCCR1W |
|
Maximum ID |
420mm |
|
Length |
3000mm |
|
Machining Method |
Workpiece Rotation, Tool Rotation |
|
Type |
SRB12000/300NC1W |
|
Maximum ID |
300mm |
|
Length |
12000mm |
|
Machining Method |
Workpiece Rotation, Tool Rotation |
II、Introduction
EOOE completely introduced decades of accumulated mature technologies and advanced production management experiences from Japan. Relying on our strong technical R&D tem, we specialize in the development and manufacture of CNC skiving roller burnishing machine and make efforts to solve various processing problems for customers. The key device configuration is imported with original packaging. Several Japanese professionals are employed to control quality strictly according to the relevant international quality standards. So, we can provide our customers with high-quality machine tools.
III、We create extraordinary quality from all details.
|
Lathe Bed |
HT300 material, high frequency quenching, ultra wide guide equipment, good stability, the weight of the body, installed without screws |
 |
|
Main Shaft (Boring Bar) |
Boring bar with high quality alloy steel material, solid round steel wool embryo processing and carburizing and quenching treatment, ensure the boring bar high rigidity, wear resistance, to ensure the machining accuracy of the workpiece |
 |
|
Workpiece Main Shaft |
Workpiece head is mobile, easy for loading and unloading |
 |
|
Workpiece Steady Rest |
V bracket roller, prevent scratch, automatically clamping and lifting. |
 |
|
Pressure Head & Hydraulic Cone Disc |
Pressure head drive by servo motor & ball screw Cone disc clamping by hydraulic power |
 |
|
Boring Bar Damper |
Prevent boring bar vibration, assure the accuracy |
 |
|
Ball Screw |
Main shaft drive by ball screw, increase the accuracy |
 |
|
Chip Conveyor |
Chain conveyor collect chip, and big chip can install crusher |
 |
|
Cutting Fluid Filtering System |
Multi-filtering to assure purity of cutting fluid, increase machining quality |
 |
|
Magnet Separator & Paper Filter |
Separate tiny chip in the cutting fluid |
 |
|
Mist Separator |
Reduce environment pollution |
 |
|
CNC Controller |
SEMENS, FANUC,MITSUBISHI |
 |
|
Tool |
Germany |
 |
|
Automation Device |
Automatic feeding, reduce operation time |
|
|
Lubricating device |
Gear lubrication by oil lubrication, bearing lubrication lubrication, and rail contact surface lubrication for centralized lubrication |
IV、On-site pictures
